CoolerMaster PSU Silent PRO GOLD 800W
[RS-800-80GA-D3]

Каталожен №: ++973   Производител: CoolerMaster

Характеристики:

• Hybrid Transformer™:

  Specially design transformer to improve thermal and efficiency.

  Patent design transformer mount with heat sink, the size was reduced by up to 25% than the traditional transformer providing lesser energy consumption, while conducting the heat for better overall efficiency



• HTT™ - Heat Transfer technology:

  Patent design “L” shaped heat sink layout.

  This technology helps to guide the air flow along the heat sink to improve the air circulation for maximum performance.



• Hyper Path™:

  Patent design hyper link between IC and the relative components.

  Patent energy conversion design path provides super efficient connection from the transformer to components. The signal can be transfer directly without any energy loss.



• Single 12 V Power Rail
  Tackling challenges from the most power-intensive peripherals head on, this solitary 12 V power rail provides ample power and strong resistance to any overloading.



• Double-Layer EMI Filter
  Dual protection from electromagnetic interference, thus restraining noise and interference for greater protection for you and your connections.



• Intel Compliant
  ATX12V v 2.3 and EPS version 2.91 compliant.



• Intelligent Fan Speed Control
  Speed control makes the 120 mm fan adept for any user’s circumstances and need.



• Active PFC+ PWM Combo Controller
  Integrating this active controller will increase the efficiency of any computer, making PFC higher than 99%.



• Multiple Protection Design
  Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Over Temperature Protection (OTP), Short Circuit Protection (SCP) and Over Current Protection (OCP).



• Efficient Transformer
  - Adeptly holding power for minimal loss in the 5V standby voltage so the system is promptly up and ready from power on or sleep modes
  - Highly efficient design on par with 80Plus Gold requirements (90% typical).



• And More
  - Multiple updated connectors for all types of interfaces (PCIe, SATA etc.)

  - Simple cable management utilizing flat modular cables for increased airflow.

  - High reliability with an MBTF of at least 100,000 hours of use.
  - NVIDIA SLI-Ready Certified guarantees enough ample power and up-to date connectors for SLI graphics cards.
  - Japanese made capacitors

  - Five Year Warranty.


Specifications

dexgo.com Overall, because of the available ports, convinced the Silent Pro gold and is in the 600-watt version interesting for smaller systems. » Details

hardware academy Cooler Masters rookie has shown that it is a good gold-power when it at one point or another still room for improvement there too. Well we like the rugged exterior, the Engineering and the operating temperature. Well we like the rugged exterior, the Eingagsfilterung and the operating temperature. Can improve the cable lengths and especially the fans. Can improve the cable lengths and especially the fans. At a price of currently about 140 €, the Pro Gold 800W Silent changes hands. At a price of currently about € 140 per Gold 800W Silent changes hands. A justifiable price. A justifiable price. We forgive our Silver Award. We forgive our Silver Award. » Details

awardfabrik.de The Cooler Master here deserves the Gold Award. The 12V rail is brick hard and hardly falls between idle and load. The 5V rail is something recognized including, but not alarming and the 3V rail one also sees a stable course. Only the fact that there are better, it can be a Silent Award just scrape by, but does not in the statement that it is a silent power supply. Finally, it gets even for his outstanding fuel economy, the Green Wheel! » Details

tomshardware.com The Silent Pro 800 Gold is a powerful PSU with no weaknesses, which is convincing in every performance area with high efficiency and stable voltages. » Details

hardware.info Cooler Master shows no exaggeration to have. The 800W model is certainly a high-performance power supply. The test results show that is very efficient, which is also stable. While slightly above the noise is completely silent but it does not really affect the power supply. Compared with other 800 and 850 W power supplies is that a market price. Of all the power supplies of 800 and 850 W during the past year tested the Coolermaster know the highest average efficiency gain. All other tested power supplies do it one step less, overall, this CoolerMaster a two to five percent or more economical. An additional advantage is that the dimensions of this modest than those of many others in this class. In short, the Cooler Master Silent Pro 800W Gold is highly recommended and we reward with a Silver Award Hardware.Info. » Details

Vortez Hardware Cooler Master go from strength to strength and with this latest series of power supplies they have pulled themselves right up into the top echelon of PSU brands. The 80 PLUS GOLD certification is clearly something that they are very proud of (given the whole name/packaging thing they have going on!) - and why not! They have produced a PSU with outstanding efficiency even at idle levels, and one which seems to generate almost no heat either! They have managed to beat the mighty Corsair HX850W in a fair number of our tests, and have come a close second in others. I would have no hesitation in recommending this brand new range of units to anyone looking for a top quality PSU. » Details
