Introduction
Cooler Master adds M850 and M1000 to the Silent Pro series, giving extreme overclockers and/or ultra high-end systems all the power they need. With up to 80A on a single 12V rail, these power supplies deliver where it counts and won’t have any problems powering even the most demanding multi-graphic card systems. These units feature flat modular cables for improved airflow and cable management. It also comes with shock absorbtion silicon pads to remove possible vibrations.
Features
Specifications
| Model | RS-850-AMBA-J3 |
| Type | Intel ATX12V V2.3 ? SSI EPS 12V V2.92 |
| Dimension (W / H / D) | 150(W) x 86(H) x 165(L) (mm) |
| Input Voltage | 90~264V (Auto Range) |
| Input Current | 12A@115Vac, 6A@230Vac |
| Input Frequency Range | 47~63Hz |
| PFC | Active PFC >0.9 |
| Power Good Signal | 100~500ms |
| Hold Up Time | >17ms |
| Efficiency | 85% Typically |
| MTBF | >100,000hrs |
| Protection | OVP/ UVP/OCP/OPP/OTP /SCP |
| Output Capacity | 850W |
| Max. Output Capacity | 1020W |
| Operation Temperature | 0~40°C (Nominal Input Voltage) |
| Regulatory | TUV / CE / GOST / C-tick / UL / FCC / CCC / BSMI |
| Fan | 135mm ultra silent fan |
| Certifications | SLI / 80 Plus Bronze |
| Connector | M/B 20+4 Pin Connector x 1 CPU 4+4 Pin x 2 PCI-E 6+2 Pin x 6 4 Pin Peripheral x 6 SATA x 9 4 Pin Floppy x 1 |
