| Intel Socket 130W | AMD Socket 125W |
| LGA2011/LGA1366/LGA1156/LGA1155/LGA1150/LGA775 | FM2/FM1/AM3+/AM3/AM2+/AM2/940/939/754 |
|
Core i7/i5/i3 Core 2 Extreme Core 2 Quad Core 2 Duo Pentium/Pentium G Pentium D/Pentium 4 Celeron Dual-Core Celeron/Celeron D |
FX X8/X6/X4 A10/A8/A6/A4 Phenom II X6/X4/X3/X2 Phenom X4/X3 Athlon II X4/X3/X2 Athlon X2 Athlon/Athlon FX Business Class Sempron |
| Overall Dimension | Fan Dimension | Net Weight | Bearing Type | |||
|
103X94X135mm（With 2Fan）
|
92X92X25mm
|
343g （With Fan）
|
Hydro Bearing | |||
| Rated Voltage | Operating Voltage | Started Voltage | Rated Current | |||
| 12VDC | 10.8～13.2VDC | 7VDC |
0.2±10%A 0.19±10%A(MAX)
|
|||
| Power Input | Fan Speed | Max. Air Flow | Noise | |||
|
2.4W 2.28W
|
2200±10%RPM 900±150~2200±10%RPM
|
42.95CFM
|
17.8~30.1dB(A)
|
