AMD
[NH-L12]
№: ++1251 Manufacturer: Noctua

€50 62

Notify me of updates to

available: no
This product is not available
50.62 EUR

Specifications:

Specifications

The NH-L12 is a low-profile quiet cooler designed for use in small form factor cases and HTPC environments. With its flexible NF-F12 (120mm) / NF-B9 (92mm) dual PWM fan setup, the NH-L12 can be configured either for full performance in dual fan mode or extra-low profile (66mm) with the top fan removed. Bundled with the award-winning NT-H1 thermal compound and Noctua’s SecuFirm2™ multi-socket mounting system, the NH-L12 packs everything a premium quality quiet cooler needs into a highly compact package.

Caution: The NH-L12 is a low-profile quiet cooler designed for use in small form factor cases and HTPC environments. While it provides first rate performance in its class, it is not suitable for overclocking and should be used with care on CPUs with more than 95W TDP (Thermal Design Power). Please consult our TDP guidelines to find out whether the NH-L12 is recommended for your CPU.

Socket compatibility		Intel LGA2011, LGA1366, LGA1156, LGA1155, LGA775 & AMD AM2, AM2+, AM3, AM3+, FM1 ( backplate required )



Height (without fan)		66 mm



Width (without fan)		128 mm



Depth (without fan)		150 mm



Height (with fan)		93 mm



Width (with fan)		128 mm



Depth (with fan)		150 mm



Weight (without fan)		415 g



Weight (with fan)		680 g



Material		Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating



Fan compatibility		120x120x25mm & 92x92x25mm



Scope of Delivery		1x NF-F12 PWM premium fan 1x NF-B9 PWM premium fan 2x Low-Noise Adaptor (L.N.A.) Y-Split Cable NT-H1 high-grade thermal compound SecuFirm2™ Mounting Kit Mini-ITX Mounting-Kit Noctua Metal Case-Badge



Warranty		6 Years



Fan specifications



Model		Noctua NF-F12 PWM & Noctua NF-B9 PWM



Bearing		SSO-Bearing



Max. Rotational Speed (+/- 10%)		1500 / 1600 RPM



Max. Rotational Speed with L.N.A. (+/- 10%)		1200 / 1300 RPM



Min. Rotational Speed (PWM)		300 / 300 RPM



Max. Airflow		93,4 / 64,3 m³/h



Max. Airflow with L.N.A.		74,3 / 52,6 m³/h



Max. Acoustical Noise		22,4 / 17,6 dB(A)



Max. Acoustical Noise with L.N.A.		18,6 / 13,1 dB(A)



Input Power		0,6 / 0,96 W



Voltage Range		12 V



MTBF		> 150.000 h

Details

	120/92mm dual fan design Thanks to its exquisite dual fan setup consisting of Noctua’s highly optimised NF-F12 (120mm) and NF-B9 (92mm) premium fans, the NH-L12 pushes the bar in terms of low-profile quiet cooling performance.
	Extra-low profile in 92mm single-fan mode The NH-L12 can be used with the NF-B9 92mm fan only in order to reduce the overall height to 66mm. This way, the cooler is suitable for many typical µATX or Mini-ITX enclosures and ideal for whisper-quiet HTPC systems.
	PWM support and Low-Noise Adaptors The NH-L12’s NF-F12 and NF-B9 fans support PWM for convenient automatic speed control. In addition, the maximum fan speed can be reduced to 1200/1300rpm using the supplied Low-Noise Adaptors for even quieter operation.
	SecuFirm2™ mounting system Noctua’s enthusiast grade SecuFirm2™ multi-socket mounting provides broad socket compatibility (LGA 2011, LGA1366, LGA1156, LGA1155, LGA775, AM2, AM2+, AM3, AM3+, FM1) and meets the highest demands in safety, performance and ease-of-use.
	Mini-ITX mounting without backplate Some Intel based Mini-ITX mainboards don’t allow for the installation of backplates. The NH-L12 thus comes with an extra set of Intel mounting bolts which make it possible to install the cooler without using the SecuFirm2™ backplate.
	NT-H1 thermal compound Noctua's much-acclaimed NT-H1 is a well proven pro-grade TIM solution that provides minimum thermal resistance, excellent ease-of-use and outstanding reliability.
