Socket 1366 / 775
Socket LGA1156 - kit sold separately
Features
Larger surface area than any other heatsinks (140mm x 120mm) with option to install one or even two 140mm fans
Designed for better air flow management to work with the heatsink fans* and the air inside your computer case
Four large 8mm heatpipes to distribute massive amount of heat fast and efficiently
Optional to rotate the heatsink 90 degrees to best fit your system configuration
Multi-platform compatible backplate for installation on vast number and type of motherboard. No need for complicated tools to convert
Heat pipes soldered to base (nickel plated)and fins for optimum heat transfer
Technical Spec
| Heatsink Body |
- Dimension : L146.2 x W124 x H161 mm (heatsink only)
- Weight : 790g (Heatsink Only)
- Recommended Fan : All 120mm & 140mm Fan
|
Compatibility
INTEL: All Intel Socket LGA 1366 / 775 processors
Components
 |
 |
 |
 |
 |
|
IFX-14-140 |
775 Bracket Mount*2 |
775 Backplate |
Mounting Plate*1 |
Spring-loaded screw*2 |
 |
 |
 |
 |
 |
|
Screws *4 |
|
Fan wire clip*4 |
Anti-ration strip *4 |
IFX-14 1366 BTK |
 |
|
|
|
|
| CF2 Thermal Paste*1 |
