| Available Color |
Black |
| |
| Dimension (W / H / D) |
Main: 253 x 502 x 563 mm / 10.0 x 19.7 x 22.2 inches
Box: 285 x 550 x 605 mm / 11.2 x 21.7 x 23.8 inches |
| |
| Weight |
Net Weight: 8.7 / 10.9 kg
Gross Weight: 19.2 / 24.0 lbs |
| |
| Material |
Steel + Plastic and Mesh Bezel |
| |
| Motherboards |
ATX / Micro-ATX |
| |
| 5.25" Drive Bay |
5 Exposed (one could convert to 3.5" drive bay) |
| |
| 3.5" Drive Bay |
5 Hidden
1 Exposed (converted from one 5.25" drive bay) |
| |
| I/O Panel |
USB 2.0 x 2, MIC x 1, Audio x 1 (supports HD / AC97 Audio), eSATA x 1 |
| |
| Cooling System |
Front: 200 mm fan x 1 Red LED on / off fan x 1 / 700 RPM / 19 dBA
(can be swap for 120 / 140 mm fan x 1)
Top: 200 mm fan x 1 / 700 RPM / 19 dBA (can be swap to 120 mm fan x 2 )
Rear: 120 mm fan x 1 / 1200 RPM / 17 dBA
Bottom: 120 / 140 mm fan x 1 (optional)
Side: 200 mm fan x 1 (optional)
(can be swap for 120 mm fan x 2) |
| |
| Expansion Slots |
7 + 1 |
| |
| Power Supply |
ATX PS2 / EPS 12V (optional) |
| |
| Optional Component |
Transparent Acrylic Side Panel |
